LiFePo4 Battery
Nominal capacity:120Ah
Nominal Voltage:3.2V
AC impendence(1KHz):≤0.3mΩ Testing within 7 days after shipment(30% SOC)
Battery Weight: ≤2.86kg
Standard charge current:1C, in 25±2℃
Peak pulse charge current: 2C, in 25±2℃,50%SOC ,30s
Standard discharge current: 1C in 25±2℃
Maximum continuous discharge current: 2C, 25±2℃
Peak Puls discharge current: 3C, 25±2℃,50%SOC, 30s
Operating Voltage:
2.5~3.65V, T>0℃
2.0~3.65V T≤0℃
Operation temperature:
0~50℃, Charge
~20-55℃ Discharge
~30-45℃ Store
Voltage tolerance test for dielectric film 0~10mA AC1500±5V;pressure800±20kg
Relative humidity:65±20%, Ambient Tempt: 25±2℃; Barometric pressure: 86~106kPa
