Wide Operating Range
1. All main components are DC frequency conversion technologies, with electronic expansion valve for precise adjustment, can ensure the stable operation of - 25℃~35 ℃ ambient temperature heating, - 25 ℃~43 ℃ ambient temperature for hot water, - 5 ℃~52 ℃ ambient temperature operation for cooling
2. Only with compressor, the maximum outlet temperature of heating wat

Energy Efficiency
The energy efficiency grade for whole series of Low Average working conditions meets A+++, and the energy efficiency grade of Medium Average meets A++

Flexibility
According to the actual installation conditions and using habits, users can choose one of the four control methods: outlet temperature control, indoor temperature sensor control, indoor temperature controller control, and buffer tank control to make the room comfortable and meet the users requirements

Dual-temperature Control
Association control mixing pumps and three-way valves can be supported to ensure that high temperature water (for heating radiator) and medium and low temperature water (for underfloor heating) can be provided at the same time to meet user's requirement

ECO mode
The double temperature zone can control the inlet water temperature independently and automatically according to the change of ambient temperature

Remote upgrade
Can use APP and remote management platform to upgrade the program and use remote management platform to monitor operating status and set operating parameters, more convenience for after service

High energy efficiency
Big compressor, big condensor, big plate heat exchanger, the SCOP can achieve A+++ at 35℃ and 55℃, and the ACS can reach A+

Good heat preservation effect
More than 45mm insulation layer,When the water temperature is 55 ℃, it only drops by 7 ℃ within 24 hours

No maintenance space needs to be reserved on the side
All installation and maintenance are completed on the front side,No need to reserve installation and maintenance space on the side

Build in 3-way valve
Build in 3-way valve,separate connection of domestic hot water and heating/cooling pipe,more convenient of installation

Wide Operating Range
1. All main components are DC frequency conversion technologies, with electronic expansion valve for precise adjustment, can ensure the stable operation of - 25℃~35 ℃ ambient temperature heating, - 25 ℃~43 ℃ ambient temperature for hot water, - 5 ℃~52 ℃ ambient temperature operation for cooling
2. Only with compressor, the maximum outlet temperature of heating wate

Energy Efficiency
The energy efficiency grade for whole series of Low Average working conditions meets A+++, and the energy efficiency grade of Medium Average meets A++

Flexibility
According to the actual installation conditions and using habits, users can choose one of the four control methods: outlet temperature control, indoor temperature sensor control, indoor temperature controller control, and buffer tank control to make the room comfortable and meet the users requirements

Dual-temperature Control
Association control mixing pumps and three-way valves can be supported to ensure that high temperature water (for heating radiator) and medium and low temperature water (for underfloor heating) can be provided at the same time to meet user's requirement

ECO mode
The double temperature zone can control the inlet water temperature independently and automatically according to the change of ambient temperature

High energy efficiency
The water temperature is 35℃ and 55℃,
SCOP is A+++

Multiple noise reduction
The compressor is wrapped with sound-absorbing materials
With damping material in the middle
Folded edge fan has a large angle design to reduce vortex noise
Unique mesh cover to reduce wind resistance
Built-in sound insulation cotton in many places
The noise of the outdoor unit is as low as 35dB three meters away

Explosion-proof
Airtight electric control box,
separated from leaked refrigerant
Explosion-proof joints and parts

Parallel connection of multiple machines
Up to 8 units can be connected in parallel, the capacity can up to 128kW
Can freely choose the number of domestic hot water units, suitable for sce

Module rotation
Sitting in the office, remotely monitoring the units operation status and modifying operation parameters
