Expansion joints

Special welding gun for use with Clip-pin insulation welding pins. A special microswitch triggers the welding operation and guarantees a consistent welding quality. It has an integrated spring pressure adjustment system for insulation with high bulk density (e.g. DUCTROCK).

Clip-Pin welding pins
Ø 2,7 mm,
L 14,5–152,4 mm
Steel/stainless steel

Aluminium – stretchable piping and highly-flexible aluminium hoses are high robust air pipes with high temperature and fire resilience. For all low, medium and high-pressure ventilation and air conditioning systems. Depending on the model, the ducts may be suitable for heat and sound absorption.

Configuration
Highly-flexible made of aluminium or aluminium laminate.

Types
With glass-fibre insulation; With coating (PVC or aluminium polymer)

Delivery
Tied up in bundles; extendable to 5 or 10 m

Diameter
From 65 mm to 710 mm; depending on the type

Made to measure.
Using special software and with the highest standards of craftsmanship.
Bohl special compensators are used in a wide variety of systems. Using sophisticated technology combined with experience and precise craftsmanship, we are able to customise our products and manufacture them individually to meet all sorts of different requirements.

Typical areas of use are:

• Power stations
• Dust extraction units
• Industrial furnaces
• Incineration plants
• Smelting works
• Paper factories
• Cement and lime works

Fabric compensators are used to balance out expansions and vibrations in pipework systems. The movements can be axial, lateral and angular and may occur alone or simultaneously. Bohl compensators are designed using a configuration programme, taking into account all the all the technical requirements as regards temperature, pressure and movement. The operating parameters determined form an integral part of our offer.

Individual processing also continues in our production unit. Every single compensator is made using a mould. The materials determined by the design software are built up layer by layer and, depending on their characteristics, are sewn, welded or joined using a special adhesive process. For all our compensators, we also offer any flanges, ducting, fixing and assembly material needed. Bohl fabric compensators are easy to assemble and can generally be installed by the customer. If you cannot install them yourself, our specialist staff will take over installation.

Almost nothing is impossible.

The diversity of fabric.

Because of the enormous range of possible uses, the requirements for the material structure are determined individually. Food-safe, silicone-free, resistant to acids, alkalis and solvents - these are just some examples of the span of the various fabrics. The use of these types of fabric depends on the medium at hand and guarantees the optimum design of the compensator to suit the existing operating parameters of your system.
Multi-layered compensators are generally made up of three areas: With one- or two-layer compensators, these functions are provided by fabrics with a corresponding coating.

All the materials used are tested by our suppliers and are subjected to further testing in our company before and during production. This allows us to maintain consistently high standards of quality.

Stud welder

The Bohl GS 100 accu+ stud welder equipment can be used in battery or mains mode as required. The battery can be charged via the device.
The welding machine provides a high level of safety, is highly suitable for work on site and is easy to operate. Optimum welding results with different welding elements and a long working life are further characteristics of the Bohl GS 100 accu+.

Working Range

• Clip-Pin welding pins DN 2.7 mm,
• Clip DN 30 mm
• Pin copper-plated steel/Clip galvanized steel
• Pin stainless steel/Clip galvanized steel

Installation speed

• 15–20 pins / min

Power source

• Capacitor 100,000 μF

Mains voltage

• 100 V to 230 V 50/60 Hz 10 AT

Battery operation

• 25,2 V

Battery capacity

• about 400 welding pins

Dimensions and weight

• 365x190x240 mm (length x width x height)
• 12 kg (stable sheet metal housing)
