3741 BRIcamL pipe inspection camera system
BRINKO pipe inspection camera system "BRIcamL" with swivelling camera head, only 28 mm diameter and 40 m fiberglass push cable, intelligent, compact design, paired with simple operation and easy transport thanks to aluminum frame.
Complete with transmitter module, this waterproof system can be used from DN70 to DN160 and can be tracked and localized by locating devices operating at 512 Hz. The camera head of the "BRIcamL" can be rotated through 360° and swivelled through 210° and is self-levelling, enabling precise tracing of connections and checking of branches. The display unit is housed in a robust, watertight and airtight plastic case and can be separated from the push cable unit in cramped working conditions or for better transportation.
The 10" TFT monitor, with a resolution of 800 x 600 pixels, detects even the smallest damaged areas and also displays the number of meters.
The "BRIcamL" is equipped with a multifunctional control panel with QWERTY keyboard for text input, as well as an integrated microphone for voice recording during video recording on SD card or USB stick.
Even for cleaning the push cable after use, this intelligent system has a device that removes the adhering water and impurities when the fiber optic cable is pushed back. These are collected in the watertight base body, which can then be emptied outdoors.
Integrated, dimmable LEDs ensure excellent illumination.
By unscrewing the transmitter unit and inserting an optional adapter, it can be used from DN50 (without bends).
This system can also be operated with a 10 or 20 meter long steel reel with Ø 12 mm camera head (use from DN20, without bends).
