line alpha_400
colour chrome
maximum width 270 mm
centre distance 150 ± 15 mm
S-connectors 1/2"
outlet to shower 1/2"
control element thermo element and ceramic head part
materials in accordance with German Drinking Water Regulations and FEA
for wall mounting
protected against backflow
with covered S-connections
suitable for instantaneous water heaters
temperature control handle
with hot water safety stop at 38°C
without shower set

threaded connector 1/2"
installation depth 70-95 mm
materials in accordance with German Drinking Water Regulations and FEA
suitable for conc. bath and shower mixer
single lever mixers and thermostats
with flushing and hydraulic test device
sealing collar and noise isolation
with distance frame
optional accessories with spacer sleeves for rear panel installation

vivana
chrome
reach 175 mm
height to aerator 180 mm
maximum height 330 mm
cartridge cartridge 35 mm
with hot water limiter
spout swivelling and extractable
materials in accordance with German Drinking Water Regulations and FEA
lever metal
flexible hoses 3/8" DIN DVGW
aerator flow rate class A
single hole mounted
with metal shower hose
lateral control
protected against backflow
with shaft screw connection

alpha-style_600
chrome
reach 150 mm
height to aerator 210 mm
maximum height 280 mm
cartridge open cartridge 35 mm
with hot water and flow rate limiter
spout swivelling
materials in accordance with German Drinking Water Regulations and FEA
lever metal
flexible hoses 3/8" DIN DVGW
aerator 7 l/min
Caché, anti lime
single hole mounted
lateral control
with pop-up waste 1 1/4"
with mounting kit

line alpha_400
colour chrome
maximum width 270 mm
centre distance 150 ± 15 mm
S-connectors 1/2"
outlet to shower 1/2"
control element thermo element and ceramic head part
materials in accordance with German Drinking Water Regulations and FEA
for wall mounting
protected against backflow
with covered S-connections
suitable for instantaneous water heaters
temperature control handle
with hot water safety stop at 38°C
without shower set

threaded connector 1/2"
installation depth 70-95 mm
materials in accordance with German Drinking Water Regulations and FEA
suitable for conc. bath and shower mixer
single lever mixers and thermostats
with flushing and hydraulic test device
sealing collar and noise isolation
with distance frame
optional accessories with spacer sleeves for rear panel installation

vivana
chrome
reach 175 mm
height to aerator 180 mm
maximum height 330 mm
cartridge cartridge 35 mm
with hot water limiter
spout swivelling and extractable
materials in accordance with German Drinking Water Regulations and FEA
lever metal
flexible hoses 3/8" DIN DVGW
aerator flow rate class A
single hole mounted
with metal shower hose
lateral control
protected against backflow
with shaft screw connection
