※Pressure-balancing diaphragm technology maintains outlet temperature within +/-3 degrees Fahrenheit during water pressure fluctuations.

※Provides temperature regulation and automatic anti-scald protection.

※Back-to-back capability.

※Single handle controls both on/off activation and temperature setting.

※Includes faceplate with ADA-compliant metal sculpted lever handle.

※Includes single-function 1.75 gpm (gallons per minute) showerhead.

※Pull-up tub spout diverts water from the spout to the shower head.

※The Hsien Chang Series is ASSE 1016-P listed and cUPC and WaterSense certified.

The BT-T39LF-38 thermostatic mixing valves maintain and limit hot water to desired selectable temperature
between 80°F and 120°F (27°C and 49°C) with flow rates as low as 0.25 gpm (1.0 lpm) and as high as 2.25 gpm
(8.5 lpm). The mixing valve is listed to ASSE 1070 for single fixture applications and IAPMO cUPC.

The BT-T39LF-38 features a rapid response thermostatic element for superior control. The thermostatic
element senses the outlet water temperature and reacts to maintain a constant delivery temperature even
under changing flows or variations in supply temperatures or pressures. It provides stable operation at flow
rates as low as 0.25 gpm (1.0 lpm). The valve also reduces the outlet flow to a trickle in the event of a cold water
supply failure.

The BT-T39LF-38 has inlet a compression connection to 3/8" OD tube. Supplied standard with integral check
valves on both inlets to prevent cross-flow.

The AT-T34LF504-34MIP Designed for individual and multiple lavatory applications where the temperature of hot water must be controlled for safe, economic use. An advanced thermal actuator quickly senses and compensates for outlet temperature fluctuations induced by water temperature and pressure changes in the supply line. The Series AT-T34LF504-34MIP features Vernet advanced paraffin-based actuation technology, integral checks and inlet screens to prevent cross-flow and contamination. Rugged construction features solid Lead Free* brass body and corrosion-resistant internal components ensuring years of dependable, trouble-free service. Temperature adjustment handle is simple to adjust and has a locking mechanism to prevent tampering. The Hsien Chang Series AT-T34LF504-34MIP is ASSE 1016-T and 1070 listed and cUPC and NSF 61-9 & 372 certified.

The BT-T40LF-38 thermostatic mixing valves maintain and limit hot water to desired selectable temperature
between 80°F and 120°F (27°C and 49°C) with flow rates as low as 0.25 gpm (1.0 lpm) and as high as 2.25 gpm
(8.5 lpm). The mixing valve is listed to ASSE 1070 for single fixture applications and IAPMO cUPC.

The BT-T40LF-38 features a rapid response thermostatic element for superior control. The thermostatic
element senses the outlet water temperature and reacts to maintain a constant delivery temperature even
under changing flows or variations in supply temperatures or pressures. It provides stable operation at flow
rates as low as 0.25 gpm (1.0 lpm). The valve also reduces the outlet flow to a trickle in the event of a cold water
supply failure.

The BT-T40LF-38 has inlet a compression connection to 3/8" OD tube. Also available with cold water bypass.
Supplied standard with integral check valves on both inlets to prevent cross-flow.

※Pressure-balancing diaphragm technology maintains outlet temperature within +/-3 degrees Fahrenheit during water pressure fluctuations.

※Provides temperature regulation and automatic anti-scald protection.

※Back-to-back capability.

※Single handle controls both on/off activation and temperature setting.

※Includes faceplate with ADA-compliant metal sculpted lever handle.

※Includes single-function 1.75 gpm (gallons per minute) showerhead.

※Pull-up tub spout diverts water from the spout to the shower head.

※The Hsien Chang Series is ASSE 1016-P listed and cUPC and WaterSense certified.

The BT-T39LF-38 thermostatic mixing valves maintain and limit hot water to desired selectable temperature
between 80°F and 120°F (27°C and 49°C) with flow rates as low as 0.25 gpm (1.0 lpm) and as high as 2.25 gpm
(8.5 lpm). The mixing valve is listed to ASSE 1070 for single fixture applications and IAPMO cUPC.

The BT-T39LF-38 features a rapid response thermostatic element for superior control. The thermostatic
element senses the outlet water temperature and reacts to maintain a constant delivery temperature even
under changing flows or variations in supply temperatures or pressures. It provides stable operation at flow
rates as low as 0.25 gpm (1.0 lpm). The valve also reduces the outlet flow to a trickle in the event of a cold water
supply failure.

The BT-T39LF-38 has inlet a compression connection to 3/8" OD tube. Supplied standard with integral check
valves on both inlets to prevent cross-flow.

The AT-T34LF504-34MIP Designed for individual and multiple lavatory applications where the temperature of hot water must be controlled for safe, economic use. An advanced thermal actuator quickly senses and compensates for outlet temperature fluctuations induced by water temperature and pressure changes in the supply line. The Series AT-T34LF504-34MIP features Vernet advanced paraffin-based actuation technology, integral checks and inlet screens to prevent cross-flow and contamination. Rugged construction features solid Lead Free* brass body and corrosion-resistant internal components ensuring years of dependable, trouble-free service. Temperature adjustment handle is simple to adjust and has a locking mechanism to prevent tampering. The Hsien Chang Series AT-T34LF504-34MIP is ASSE 1016-T and 1070 listed and cUPC and NSF 61-9 & 372 certified.
