Description

Software for the MEP Design and calculations

LINEAR for Autodesk AutoCAD

Since the early 90s LINEAR develops its CAD software as a powerful application for AutoCAD and its corresponding vertical products AutoCAD Architecture and AutoCAD MEP. The program families Desktop, Design 3D and Analyse do all work with AutoCAD and make interfaces unnecessary.

LINEAR CADinside as an Alternative

As an interesting alternative to the widely used AutoCAD installations, which allow you to use applications from various origins on an open CAD platform, we also offer you our products as an independent LINEAR CADinside variant. With integrated CAD functionality made by Autodesk. From a single source! If you want to use only individual modules of our extensive CAD Solutions, the economically most reasonable solution might be the variant with an integrated CAD core. The LINEAR solutions are identical in both program versions and of course 100 % compatible.

IFC for the Open BIM Process

The integrated IFC interface also enables BIM-compliant work with AutoCAD or CADinside. The degree of detail, which is only possible when planning in 3D on these CAD systems, can thus be transferred to a BIM process. With the intelligence that a BIM model requires and all the details that enable prefabrication and "as build" planning in the first place.




  • Architecture Detection
  • Building Analysis
  • Heat Load Calculation
  • Cooling Load Calculation
  • Dimensioning of Radiators, Convectors & Panel Heating
  • Dimensioning of Cooling Convectors & Panel Cooling
  • 2D Heating Pipe Network and Central Heating Unit Design
  • 2D Cooling Pipe Network and Cooling System Design
  • 2D Air Duct Network and Air Handling Unit Design
  • 2D Potable Water Pipe Network and System Design
  • 2D Waste Water Pipe Network and System Design
  • 2D Gas Pipe Network and System Design
  • 2D Electrical Design
  • 3D Piping Design
  • 3D Air Duct Design
  • Heating Pipe Network Calculation
  • Cooling Pipe Network Calculation
  • Air Duct Network Calculation
  • Potable Water Pipe Network Calculation
  • Waste Water Pipe Network Calculation
  • Gas Pipe Network Calculation
  • IFC-Export
  • FM-Tools

More from us

Our websiteOur product

More products by LINEAR Gesellschaft für konstruktives Design mbH

LINEAR Solutions for Revit

In order to support the emerging requirements associated with BIM processes, Autodesk Revit is on its way to become a popular CAD platform preferred by MEP designers. But even without the need to satisfy BIM requirements, the concept behind Revit proves to be a logical evolution of CADbased design. The provision of several alternatives in design options and the management of several design phases such as inventory, reconstruction, expansion in one project gives the model a further benefit. The 3-dimensional construction in storeys and work levels and the simple creation of different plans for the output reflects also a great advantage of the 3D design in Revit. This, in combination with the parametric database model, results in a system that is definitely future-oriented. Revit pursues the concept of covering as many disciplines, working methods and display options as possible in a single software application. Everyone involved in the design process should be able to work with the same CAD platform. Enabling cooperation on large international projects inevitably leads to a complexity that places enormous demands on those who “only” want to realize their MEP design in Revit. This is exactly where we come in, making Revit a powerful tool for building services engineering with a multifunctional set of context-dependent tools coupled with intuitive organization options and a clearly structured user interface.




  • MEP Model Creation
  • Building Analysis
  • Heat Load Calculation
  • Cooling Load Calculation
  • Dimensioning of Radiators, Convectors & Panel Heating
  • Dimensioning of Cooling Convectors & Panel Cooling
  • Heating Pipe Network and Central Heating Unit Design
  • Cooling Pipe Network and Cooling System Design
  • Air Duct Network and Ventilation Unit Design
  • Potable Water Pipe Network and System Design
  • Waste Water Pipe Network and System Design
  • Gas Pipe Network and System Design
  • Heating Pipe Network Calculation
  • Cooling Pipe Network Calculation
  • Air Duct Network Calculation
  • Potable Water Pipe Network Calculation
  • Waste Water Pipe Network Calculation
  • Gas Pipe Network Calculation
