MEZ-SYPHON-FLANGE system 20 with injected sealing compound is an air duct profile for the manufacturing of air duct systems with high tightness requirements. By placing the sealing compound inside the MEZ-SYPHON-FLANGE you are able to meet the requirements of air tightness class C & D according to EN 1507.

The cant of the MEZ-SYPHON-FLANGE which makes it easier to insert the air duct wall and stabilises the mounting portion. Another feature which contributes to the optimal stability of the MEZ-SYPHON-FLANGE is the 45° supporting limb. To meet the high tightness requirements, the inner limb was designed with a slight cant and therefore it functions like a sealing lip.

• high tightness through integrated syphon
• profile for all purposes
• easy to insert the duct wall

i-klimaX® is a web-based solution and enables you to order rectangular and circular air duct components with almost every web-enabled device. All you or your customers, fitters or site managers need to do is go on www.i-klimax.com and log in with your i-klimaX® account. Managing your customers or users is made by yourself using the administration surface of i-klimaX®.

• access with every web-enabled device
• easy to order

e-klimaX® is our software solution to collect and order rectangular and circular air duct components. With just a few clicks you are able to send your inquiry or order to your air duct manufacturer.

• order by email
• import and export data from various CAD systems

MEZ-LATZ is ideally suited to connect rectangular air ducts. MEZ-LATZ 506 is made of galvanised steel and convinces with an increased stability due to the double ribbing and therefore it is suitable for large duct cross-sections as well as for high pressure conditions.

Due to the pre-assembled hexagonal bolt there is no need to pre-clambing or drilling and the assembly of this air duct clamp is very easy. No matter if you are using MEZ-FLANGE-SYSTEM 20, 30 or 40 or any other flange connections you are able to connect them with MEZ-LATZ 506.

• air duct clamp
• galvanised steel
• for system 20, 30 and 40
• increased stability due to double ripping
• suitable for large duct cross-sections as well as high pressure conditions

MEZ-SYPHON-FLANGE system 20 with injected sealing compound is an air duct profile for the manufacturing of air duct systems with high tightness requirements. By placing the sealing compound inside the MEZ-SYPHON-FLANGE you are able to meet the requirements of air tightness class C & D according to EN 1507.

The cant of the MEZ-SYPHON-FLANGE which makes it easier to insert the air duct wall and stabilises the mounting portion. Another feature which contributes to the optimal stability of the MEZ-SYPHON-FLANGE is the 45° supporting limb. To meet the high tightness requirements, the inner limb was designed with a slight cant and therefore it functions like a sealing lip.

• high tightness through integrated syphon
• profile for all purposes
• easy to insert the duct wall

i-klimaX® is a web-based solution and enables you to order rectangular and circular air duct components with almost every web-enabled device. All you or your customers, fitters or site managers need to do is go on www.i-klimax.com and log in with your i-klimaX® account. Managing your customers or users is made by yourself using the administration surface of i-klimaX®.

• access with every web-enabled device
• easy to order

e-klimaX® is our software solution to collect and order rectangular and circular air duct components. With just a few clicks you are able to send your inquiry or order to your air duct manufacturer.

• order by email
• import and export data from various CAD systems
