Multifunction Detector for Gas Leakage and Spillage Test

• Reliable gas leak detection and spillage test with only one system
• Adjustable alarm thresholds
• Optical alarm at the sensor and on the display of the device
• Acoustic and vibration alarm by the device
• Strong Lithium-Ion battery, chargeable via Mini-USB socket

• Freely adjustable alarm threshold (Vibration)
• Sensor exchange possible during current operation; device identificates the sensor automatically
• Acoustical, optical and haptical alarm
• Indication of gas concentration in ppm, % and %LEL (HC sensor)
• Adjustment factors are stored in the sensor, so it can be used with different devices
• TFT colour display
• Handy device with dirt resistant keypad
• Integrated Lithium-Ion battery
• Power supply for battery charging

• Wireless remote control of all functions
• Remote control functions also as a separate measuring device
• Robust metal enclosure mounted to an aluminium framed case
• Brilliant 3,5“TFT colour display
• Storage and transfer of measuring data (SD card or USB)
• Data logging function
• Speedprinter
• Temperature measurements of all kind
• Pressure-, differential pressure- and chimney draft measurement
• Contactless battery charging, altern. through Mini-USB socket
• Lithium ion battery for 10 hours continuous operation (basic unit)

O2 0 ... 21 % NO(x) 0 ... 1.000 ppm* overload up to 5.000 ppm (option) CO (H2 compensated) 0 ... 4.000 ppm* overload up to 10.000 ppm (option) Differential pressure at basic unit ± 100hPa, at remote control ± 200hPa External pressure sensor up to 40 bar (option) Temperature up to 800 °C or up to 1.100 °C (with suitable sensor) Fluegas temperature 0 ... 800°C (stainless steel tube) 0 ... 1.100°C (inconeltube) Relative humidity 3 ... 98 % Amount of leakage 0 ... 8 l/h External temperature sensor K-type standard

Digital Manifold for installation and service in the field of refrigeration and air conditioning. An ideal tool for installation and service at air conditioning units and heat pumps.

• Integrated, robust vacuum sensor
• All refrigerants, incl. A3, such as propane R290
• Powerful battery for long-term measurement operation
• Bluetooth accessories (temperature clamp, external pressure sensor)
• App for device and accessory control, software update and measurement log

• Precise and very stable offset measuring technique by means of non dispersive infrared (NDIR) technique, for enhanced long time measurements
• Up to 8 gas NDIR measurement: CO/CO2/C3H8/CH4/SO2/NO/NO2/N2O/H2 and oxygen with O2-PM (paramagnetic cell)
• Remote control via smartphone or tablet using VCN server via LAN/WLAN (no remote control via MRU4u app)
• Wireless data transfer via Bluetooth dongle or WLAN dongle or via VNC server using LAN/WLAN

• Modern technology, high accuracy and performance
• Field replaceable plug&play sensors due to new MSM-technology
• Colour and backlit touchscreen, intuitive and easy to use
• Up to 3 electrochemical cells for O2, CO and NO
• Compatible with new MRU App "MRU4u" *
• TÜV approved according to EN 50379-1+2 (model B) resp. 50379-3 (model E), ByRgG 309

• O2-sensor
• CO-Sensor, non-H2-compensated (using CO sensor version E)
• CO-Sensor, H2-compensated (using CO sensor version B)
• MSM sensor technology for field replaceable, plug & play sensors
• Gas temperature measurement up to 1200°C with K-type thermocouple
• Combustion air temperature 0 - 100°C with K-type thermocouple
• Stack / Differential pressure: ± 100 mbar
• Differential temperature mesurement
• Ambient air CO tester
• Gas sampling probe with fixed Ø 8 x 250 mm stainless steel tube
• and 1,5 m triple silicone gas sampling hose
• Large condensate trap with Teflon coated particulate filter
• High capacity, Lithium-Ion rechargeable battery
• Mini-USB interface to PC and SD card slot for large volume data logging
• Internal data storage for up to 1.000 measurements
• IRDA printer interface

Multifunction Detector for Gas Leakage and Spillage Test

• Reliable gas leak detection and spillage test with only one system
• Adjustable alarm thresholds
• Optical alarm at the sensor and on the display of the device
• Acoustic and vibration alarm by the device
• Strong Lithium-Ion battery, chargeable via Mini-USB socket

• Freely adjustable alarm threshold (Vibration)
• Sensor exchange possible during current operation; device identificates the sensor automatically
• Acoustical, optical and haptical alarm
• Indication of gas concentration in ppm, % and %LEL (HC sensor)
• Adjustment factors are stored in the sensor, so it can be used with different devices
• TFT colour display
• Handy device with dirt resistant keypad
• Integrated Lithium-Ion battery
• Power supply for battery charging

• Wireless remote control of all functions
• Remote control functions also as a separate measuring device
• Robust metal enclosure mounted to an aluminium framed case
• Brilliant 3,5“TFT colour display
• Storage and transfer of measuring data (SD card or USB)
• Data logging function
• Speedprinter
• Temperature measurements of all kind
• Pressure-, differential pressure- and chimney draft measurement
• Contactless battery charging, altern. through Mini-USB socket
• Lithium ion battery for 10 hours continuous operation (basic unit)

O2 0 ... 21 % NO(x) 0 ... 1.000 ppm* overload up to 5.000 ppm (option) CO (H2 compensated) 0 ... 4.000 ppm* overload up to 10.000 ppm (option) Differential pressure at basic unit ± 100hPa, at remote control ± 200hPa External pressure sensor up to 40 bar (option) Temperature up to 800 °C or up to 1.100 °C (with suitable sensor) Fluegas temperature 0 ... 800°C (stainless steel tube) 0 ... 1.100°C (inconeltube) Relative humidity 3 ... 98 % Amount of leakage 0 ... 8 l/h External temperature sensor K-type standard

Digital Manifold for installation and service in the field of refrigeration and air conditioning. An ideal tool for installation and service at air conditioning units and heat pumps.

• Integrated, robust vacuum sensor
• All refrigerants, incl. A3, such as propane R290
• Powerful battery for long-term measurement operation
• Bluetooth accessories (temperature clamp, external pressure sensor)
• App for device and accessory control, software update and measurement log
