With EDOstructure you can digitally model the development process of your TFP component.

Unique functions:

• Processing of 3D CAD shell geometries for 2D pattern data generation for the TFP process
• Import and analysis of numerically simulated stress conditions as well as automated derivation of possible TFP deposit patterns, including those based on principal stresses with and without specific manufacturing parameters
• Export/import of generated pattern data in DXF format
• Easy creation of production-compliant, complex numerical simulation models and their export for various FEA solver formats
• As well as many other functionalities

With WIREpath you can quickly and easily create stitch pattern data for your wire laying applications.

You can use unique functions as:

• Fast editing of input data via one-click stitch generator for imported DXF files
• Optimized stitch distribution for higher production speed
• Optimization of the fiber course for an optimal laying process according to the original CAD pattern
• Preview of the zigzag course of the sewing thread
• Export of data sheets with exact production details
• As well as many other functionalities

EDOpath is the first CAM software specifically designed for Tailored Fiber Placement.

You can use unique functions as:

• Fast editing of input data via one-click stitch generator for imported DXF files
• Optimized stitch distribution for higher production speed
• Optimization of the fiber course for an optimal laying process according to the original CAD pattern
• Preview of the zigzag course of the sewing thread
• Export of data sheets with exact manufacturing information
• Graphical 3D display of component thickness according to the actual roving course
• Export of 3D CAD surfaces for thickness-adapted forming tools based on component fiber volume content and roving type used
• As well as many other functionalities
