Product Overview:

• Low NOx emissions (less than 20ng/J NOx or 72 mg/kWh)
• High modulation range
• Highly variable port patterns available
• Cost advantage versus mesh fiber burner alternatives

Market Segments:

• Residential boilers
• Commercial boilers
• Storage and tankless water heaters

Technical Specifications:

• Combustion type: Premix
• Power input range: 35k - 500k Btu/h (10 - 150 kW)
• Size range:
  • Available in 63 and 70 mm dia (2.5” and 2.8”)
  • Length: 70 - 450 mm (2.8" - 17.7")
• Material: Stainless steel

Product Overview:

• Highly customizable design
• Ultra low NOx emissions – less than 14 ng/J (50 mg/kWh)
• High modulation range
• High specific load

Market Segments:

• Residential and commercial boilers
• Residential furnaces
• Combi boilers
• Tankless water heaters

Technical Specifications:

• Combustion type: Premix
• Input range: 70k – 420k Btu/h (20 – 120 kW)
• Material: Metal fiber mesh and stainless steel

Product Overview:

• Designed with extensive use of CFD simulations
• Modular construction allows for variation in number of blades
• Fulfills EN and ANSI standards

Market Segments:

• Residential boilers
• Tankless water heaters

Technical Specifications:

• Combustion type: Atmospheric
• Size range: 5 to 20 blades each with length of 6.3" (160mm)
  • Available with .66", .74" and .80" (17mm, 19mm and 20.5mm) blade pitch
• Input range per blade: 2.5k - 8.5k Btu/h (0.7 - 2.5 kW)
• Power output range: 13k - 170k Btu/h (4 - 50 kW)
  • Turndown ratio 1:3
• Low Noise: < 45 dB(A).
• Material: Aluminized and stainless steel

Product Overview:

• Mesh material withstands high temperatures and protects metal body from thermal stresses
• Capable of operating in a wide modulation range
• Available with active end-cap design
• Available with optional end-cap insulation

Market Segments:

• Residential and commercial water heaters
• Residential and commercial boilers
• Gas absorption heat pump

Technical Specifications:

• Combustion type: Premix
• Input range: 35k – 17+ MBtu/h (10k – 5+ MW)
• Size range:
  • Diameter: 1.5” - 25.5” (40-650 mm)
  • Length: up to 78" (2 Meters)

Product Overview:

• Low NOx emissions (less than 20ng/J NOx or 72 mg/kWh)
• High modulation range
• Highly variable port patterns available
• Cost advantage versus mesh fiber burner alternatives

Market Segments:

• Residential boilers
• Commercial boilers
• Storage and tankless water heaters

Technical Specifications:

• Combustion type: Premix
• Power input range: 35k - 500k Btu/h (10 - 150 kW)
• Size range:
  • Available in 63 and 70 mm dia (2.5” and 2.8”)
  • Length: 70 - 450 mm (2.8" - 17.7")
• Material: Stainless steel

Product Overview:

• Highly customizable design
• Ultra low NOx emissions – less than 14 ng/J (50 mg/kWh)
• High modulation range
• High specific load

Market Segments:

• Residential and commercial boilers
• Residential furnaces
• Combi boilers
• Tankless water heaters

Technical Specifications:

• Combustion type: Premix
• Input range: 70k – 420k Btu/h (20 – 120 kW)
• Material: Metal fiber mesh and stainless steel

Product Overview:

• Designed with extensive use of CFD simulations
• Modular construction allows for variation in number of blades
• Fulfills EN and ANSI standards

Market Segments:

• Residential boilers
• Tankless water heaters

Technical Specifications:

• Combustion type: Atmospheric
• Size range: 5 to 20 blades each with length of 6.3" (160mm)
  • Available with .66", .74" and .80" (17mm, 19mm and 20.5mm) blade pitch
• Input range per blade: 2.5k - 8.5k Btu/h (0.7 - 2.5 kW)
• Power output range: 13k - 170k Btu/h (4 - 50 kW)
  • Turndown ratio 1:3
• Low Noise: < 45 dB(A).
• Material: Aluminized and stainless steel
