The C.A.T.S. Software Ventilation application is the perfect solution for planners and contractors.

It has been tried and tested in the course of many years of practical use and the experience that has been gained in this time, especially in the field of assembly planning.

Among other things, it consists of a CAD system for schematic and ground plan planning, an integrated pressure drop calculation as well as a complete bill of quantities.

In this regard, C.A.T.S. offers the following products:

• Ventilation 3D Layout Planning
• Ventilation Pressure Loss
• Ventilation Schema Calculation

With the C.A.T.S. Software Sprinkler programme, the sprinkler system is drawn with simple CAD functions, using the single-line method.

Once the calculation is completed, the sprinkler network can also be designed in 3D automatically.

Sprinkler Professional satisfies all sprinkler system calculation requirements in accordance with VdS CEA 4001, FM global as well as water spray systems in accordance with VdS 2109.

What is more, the following guidelines are supported: SES (Switzerland), BS 9251 (British Standard) and NFPA 13 (National Fire Protection Association).

In this regard, C.A.T.S. offers the following products:

• Sprinkler floor plan
• Sprinkler hydraulic calculation

When working with the pipework construction module, technical centres, details or complete systems of the heating, sanitary and sprinkler trades are constructed in 3D.

Each component is drawn in its real geometry.

For this purpose, comprehensive product catalogues of well-known manufacturers are available.

It is possible to automatically generate any sections from a drawing.

The programme is characterised by its trouble-free and simple operation.

In this regard, C.A.T.S. offers the following product:

• Pipework construction

Unsere neueste Produktveröffentlichung „Elektroplanung 2.0" - bestehend aus Elektro CAD und Elektro CAE - revolutioniert die TGA-Branche nachhaltig.

Innovative Entwicklungsarbeit zusammen mit mehr als 30 Jahren Erfahrung treffen die Kernbedürfnisse der Elektroplanung zielgenau und ermöglichen eine bisher unerreichte Effizienzsteigerung in Ihren Projekten:

• Einfache Bedienung und maximales Feedback
• Planungsdokumentation, automatisch und datenkonsistent
• Netzwerkmanagement mit integrierten Berechnungs- und Analysefunktionen
• Schrittweise Verfeinerung der Planungsmodelle durch variablen Detaillierungsgrad
• Verteiltes Arbeiten in aufgeteilten Modellen durch die integrierte aModel® Technologie
• Einbindung in Open BIM Projekte über zertifizierte Schnittstellen

Das Programm C.A.T.S. Software Heizung ist die ideale Lösung für die Planung und Ausführung eines Projektes, basierend auf einem gemeinsamen Datenmodell.

Sie besteht u.a. aus einem Raummanager zur einfachen Erfassung der Gebäudedaten, einem intelligenten CAD-System für Schema- und Grundrissplanung, einer integrierten Rohrnetzberechnung und einem kompletten Massenauszug.

Auch die auf Windows basierenden Programme wie die U-Wertberechnung nach EN ISO 6946, die Heizlastberechnung nach EN 12831-1, die Auslegung der Raumheizflächen nach VDI 6030 und die Berechnung der Fußbodenheizung nach EN 1264 sind Bestandteile des Systems.

Folgende Produkte bietet C.A.T.S. diesbezüglich an:

• Heizung Grundrissplanung
• Heizung Schemaplanung
• Heizung Hydraulikberechnung für Grundriss- und Schemaplanung
• Heizung Fußbodenheizung
• Raummanager
• Heizung Heizlast/Heizkörperauslegung
