Superfast running servomotor

• 40 Nm
• Universal clamp or form fitting
• Running time 70-150 s
• IP54
• Manual operation for gearbox(incl. mech. Locking)
• 5 years warranty 60‘000 cycles (0°-90°-0°)1‘000‘000 partial cycles (±5°)
• Optional communication RS485 Modbus RTU
• Service connection for powerless parameterization
• Fail-Safe position via integrated capacitors
• Connection cable (4-wires, 6-wires), various plugs
• Continuous control

Spring return servomotor for fire and smoke protection

• 3 / 5 Nm
• Form fitting
• Running time 30 / 75 s / 90°
• IP54
• Manual winding with locking mechanism
• 5 years warranty 60‘000 cycles (0°-90°-0°) 1‘000‘000 partial cycles (±5°)
• Thermal tripping device
• Optional auxiliary switch
• Spring return
• Connection cables (3-wires, 4-wires), various plugs
• 2-/3-point, continuous control

Rotary servomotor

• 5 / 10 / 15 Nm
• Universal clamp or form fitting with and without flange fixing
• Running time 5 Nm @ 20 - 120 s / 90° | 10 / 15 Nm @ 60 - 420 s / 90°
• IP54
• Gearing latch disengaged with pushbutton, self-resetting
• 5 years warranty 100‘000 cycles (0°-90°-0°)1‘500‘000 partial cycles (±5°)
• Small size
• Optinal auxiliary switch
• Optional feedback potentiometer
• Optional communication Modbus RTU
• Display for parametrization (ModBus RTU)
• Connection cables (3-wires, 4-wires, 6-wires), various plugs
• 2-/3-point, continuous control

• Volume airflow- /pressure control
• 5 / 10 / 15 Nm
• Universal clamp or form fitting with and without flange fixing
• Running time 5 Nm @ 20 - 120 s / 90° | 10 / 15 Nm @ 60 - 420 s / 90°
• IP42
• Gear de-clutch with pushbutton, lockable
• LED test button for status indication and menu navigation
• Display for parameterization
• Service connection for powerless parameterization in combination with Win-VAV2 software
• Dynamic or static differential pressure sensor up to 1000 Pa
• 5 years warranty 100‘000 cycles (0°-90°-0°) 1‘500‘000 partial cycles (±5°)
• Small size
• Optional communication Modbus RTU / BACnet MSTP
• Connection cables (4-wires, 6-wires), screw terminal, various plugs
• Open loop, external VAV control

Superfast running servomotor

• 40 Nm
• Universal clamp or form fitting
• Running time 70-150 s
• IP54
• Manual operation for gearbox(incl. mech. Locking)
• 5 years warranty 60‘000 cycles (0°-90°-0°)1‘000‘000 partial cycles (±5°)
• Optional communication RS485 Modbus RTU
• Service connection for powerless parameterization
• Fail-Safe position via integrated capacitors
• Connection cable (4-wires, 6-wires), various plugs
• Continuous control

Spring return servomotor for fire and smoke protection

• 3 / 5 Nm
• Form fitting
• Running time 30 / 75 s / 90°
• IP54
• Manual winding with locking mechanism
• 5 years warranty 60‘000 cycles (0°-90°-0°) 1‘000‘000 partial cycles (±5°)
• Thermal tripping device
• Optional auxiliary switch
• Spring return
• Connection cables (3-wires, 4-wires), various plugs
• 2-/3-point, continuous control

Rotary servomotor

• 5 / 10 / 15 Nm
• Universal clamp or form fitting with and without flange fixing
• Running time 5 Nm @ 20 - 120 s / 90° | 10 / 15 Nm @ 60 - 420 s / 90°
• IP54
• Gearing latch disengaged with pushbutton, self-resetting
• 5 years warranty 100‘000 cycles (0°-90°-0°)1‘500‘000 partial cycles (±5°)
• Small size
• Optinal auxiliary switch
• Optional feedback potentiometer
• Optional communication Modbus RTU
• Display for parametrization (ModBus RTU)
• Connection cables (3-wires, 4-wires, 6-wires), various plugs
• 2-/3-point, continuous control
