Igniting wood, pellets and other biomass fuels

Introducing the FKK ceramic biomass igniter range, an advance in ignition technology for solid fuels.

FKK Corporation specialises in ceramic hot surface igniters and has many years experience of working closely with customers to develop bespoke solutions for innovative appliance manufacturers. We are a trusted manufacturer of hot surface ignition products to many industry sectors.

These advanced igniters are simply the best for lighting pellet and biomass burners. They use only a fraction of the energy required by hot air fans and ignition blowers and will light all fuel types. Ideal for wood pellets, chips, straw, coal, coke etc.

With a considerably higher temperature, around twice that of traditional metal sheathed products, ignition times are reduced to as little as 60 seconds. This makes them significantly more economical in use.

Ø17mm threaded insert G3/8"

Systems

• Pellet stove
• Pellet boiler
• Pellet burner

Ceramic ignition technology benefits

• A fraction of the energy consumption compared to conventional cartridge or element heater
• Long lasting
• Time to ignition 60~90 seconds
• Tested to 100,000 cycle (in Japanese pellet market for 15 years)
• Easy to install and retrofit
• 1000°C at steady-state temperature
• 100/120/220/240V forward current
• Fully electrically insulated with no exposed electric contacts
• Impervious to oxidation and corrosion
• Fully comply with the CE (TÜV certification), ROHS and REACH (TÜV certification) directives.
• Ignite wood chips, split logs, coal briquettes or other biomass, straw, corn etc.

Reducing emission values ​​and increasing efficiency: These are among the requirements for a modern biomass heating system.

Together with the company NGK|NTK, we have developed a lambda sensor especially for the biomass sector.

In order to permanently reduce emissions, regulation using a lambda sensor is state of the art. Lambda sensor technology was developed in the 1970s and has been used as standard in the automotive sector since 1976. In the automotive sector, the lambda sensor regulates the ratio of fuel and air in order to achieve optimum efficiency with the lowest emissions. This principle of measuring the residual oxygen in the exhaust gas is also used when burning biomass (logs, wood chips, pellets).

Igniting wood, pellets and other biomass fuels

Introducing the FKK ceramic biomass igniter range, an advance in ignition technology for solid fuels.

FKK Corporation specialises in ceramic hot surface igniters and has many years experience of working closely with customers to develop bespoke solutions for innovative appliance manufacturers. We are a trusted manufacturer of hot surface ignition products to many industry sectors.

These advanced igniters are simply the best for lighting pellet and biomass burners. They use only a fraction of the energy required by hot air fans and ignition blowers and will light all fuel types. Ideal for wood pellets, chips, straw, coal, coke etc.

With a considerably higher temperature, around twice that of traditional metal sheathed products, ignition times are reduced to as little as 60 seconds. This makes them significantly more economical in use.

Ø17,7mm Ceramic-flange

Systems

• Pellet stove
• Pellet boiler
• Pellet burner

Ceramic ignition technology benefits

• A fraction of the energy consumption compared to conventional cartridge or element heater
• Long lasting
• Time to ignition 60~90 seconds
• Tested to 100,000 cycle (in Japanese pellet market for 15 years)
• Easy to install and retrofit
• 1000°C at steady-state temperature
• 100/120/220/240V forward current
• Fully electrically insulated with no exposed electric contacts
• Impervious to oxidation and corrosion
• Fully comply with the CE (TÜV certification), ROHS and REACH (TÜV certification) directives.
• Ignite wood chips, split logs, coal briquettes or other biomass, straw, corn etc.

Igniting wood, pellets and other biomass fuels

Introducing the FKK ceramic biomass igniter range, an advance in ignition technology for solid fuels.

FKK Corporation specialises in ceramic hot surface igniters and has many years experience of working closely with customers to develop bespoke solutions for innovative appliance manufacturers. We are a trusted manufacturer of hot surface ignition products to many industry sectors.

These advanced igniters are simply the best for lighting pellet and biomass burners. They use only a fraction of the energy required by hot air fans and ignition blowers and will light all fuel types. Ideal for wood pellets, chips, straw, coal, coke etc.

With a considerably higher temperature, around twice that of traditional metal sheathed products, ignition times are reduced to as little as 60 seconds. This makes them significantly more economical in use.

Ø26mm Ceramic-flange

Systems

• Pellet stove
• Pellet boiler
• Pellet burner

Ceramic ignition technology benefits

• A fraction of the energy consumption compared to conventional cartridge or element heater
• Long lasting
• Time to ignition 60~90 seconds
• Tested to 100,000 cycle (in Japanese pellet market for 15 years)
• Easy to install and retrofit
• 1000°C at steady-state temperature
• 100/120/220/240V forward current
• Fully electrically insulated with no exposed electric contacts
• Impervious to oxidation and corrosion
• Fully comply with the CE (TÜV certification), ROHS and REACH (TÜV certification) directives.
• Ignite wood chips, split logs, coal briquettes or other biomass, straw, corn etc.

Igniting wood, pellets and other biomass fuels

Introducing the FKK ceramic biomass igniter range, an advance in ignition technology for solid fuels.

FKK Corporation specialises in ceramic hot surface igniters and has many years experience of working closely with customers to develop bespoke solutions for innovative appliance manufacturers. We are a trusted manufacturer of hot surface ignition products to many industry sectors.

These advanced igniters are simply the best for lighting pellet and biomass burners. They use only a fraction of the energy required by hot air fans and ignition blowers and will light all fuel types. Ideal for wood pellets, chips, straw, coal, coke etc.

With a considerably higher temperature, around twice that of traditional metal sheathed products, ignition times are reduced to as little as 60 seconds. This makes them significantly more economical in use.

Ø17mm threaded insert G3/8"

Systems

• Pellet stove
• Pellet boiler
• Pellet burner

Ceramic ignition technology benefits

• A fraction of the energy consumption compared to conventional cartridge or element heater
• Long lasting
• Time to ignition 60~90 seconds
• Tested to 100,000 cycle (in Japanese pellet market for 15 years)
• Easy to install and retrofit
• 1000°C at steady-state temperature
• 100/120/220/240V forward current
• Fully electrically insulated with no exposed electric contacts
• Impervious to oxidation and corrosion
• Fully comply with the CE (TÜV certification), ROHS and REACH (TÜV certification) directives.
• Ignite wood chips, split logs, coal briquettes or other biomass, straw, corn etc.

Reducing emission values ​​and increasing efficiency: These are among the requirements for a modern biomass heating system.

Together with the company NGK|NTK, we have developed a lambda sensor especially for the biomass sector.

In order to permanently reduce emissions, regulation using a lambda sensor is state of the art. Lambda sensor technology was developed in the 1970s and has been used as standard in the automotive sector since 1976. In the automotive sector, the lambda sensor regulates the ratio of fuel and air in order to achieve optimum efficiency with the lowest emissions. This principle of measuring the residual oxygen in the exhaust gas is also used when burning biomass (logs, wood chips, pellets).

Igniting wood, pellets and other biomass fuels

Introducing the FKK ceramic biomass igniter range, an advance in ignition technology for solid fuels.

FKK Corporation specialises in ceramic hot surface igniters and has many years experience of working closely with customers to develop bespoke solutions for innovative appliance manufacturers. We are a trusted manufacturer of hot surface ignition products to many industry sectors.

These advanced igniters are simply the best for lighting pellet and biomass burners. They use only a fraction of the energy required by hot air fans and ignition blowers and will light all fuel types. Ideal for wood pellets, chips, straw, coal, coke etc.

With a considerably higher temperature, around twice that of traditional metal sheathed products, ignition times are reduced to as little as 60 seconds. This makes them significantly more economical in use.

Ø17,7mm Ceramic-flange

Systems

• Pellet stove
• Pellet boiler
• Pellet burner

Ceramic ignition technology benefits

• A fraction of the energy consumption compared to conventional cartridge or element heater
• Long lasting
• Time to ignition 60~90 seconds
• Tested to 100,000 cycle (in Japanese pellet market for 15 years)
• Easy to install and retrofit
• 1000°C at steady-state temperature
• 100/120/220/240V forward current
• Fully electrically insulated with no exposed electric contacts
• Impervious to oxidation and corrosion
• Fully comply with the CE (TÜV certification), ROHS and REACH (TÜV certification) directives.
• Ignite wood chips, split logs, coal briquettes or other biomass, straw, corn etc.
