These cartridges are produced for use in thermostatic valves on heaters and manifolds for heating systems. They are produced according to customer design and specifications

These valves are designed to separate the different areas of a building by shutting off the water locally without interrupting the general flow of water. They are available in sizes G1/2" (DN15), G3/4" (DN20), G1' (DN25), but also with other intermediate threads on request, all in long and short spindle versions with customisable heights and broaches. They have a long stroke to ensure high water flow. They can be supplied with accessories: handles, rosette, cover, thread saver, etc.

RISING SPINDLE CARTRIDGES

These are the classic cartridges with "T" handle or handwheel suitable for outdoor
taps: they are available with various threads, heights and closing depths, spline,
square T-handle, Handwheel and other connections. Unlike most of the similar articles on the market, our product DOES NOT NEED a stuffing nut in order to achieve a
perfect seal as the internal construction guarantees lubrication of the movement
and smooth rotation over time with no need for maintenance.

NON RISING SPINDLE CARTRIDGES

These are very reliable valves with two O-Rings on the spindle (to ensure tightness),
without a sealed grease chamber (oil bath). They are safe to use even though they
are suitable for economical fittings. In the Z series, the tight washer is assembled in
a cup and secured with a nut, while in the ZT series the tight washer is press-fitted
without a retaining cup. They are available with various threads, heights, closing
depths and with splines, square and special connections

NON RISING SPINDLE GREASE CHAMBER CARTRIDGES

These cartridges have the internal thread lubricated and protected by two O-rings (one on the
spindle and one on the valve) so as to form a sealed watertight chamber where the grease
remains, guaranteeing a reliable longlife. Suitable for high quality fittings, they are available
in different versions: light and heavy, with and without anti-friction washers, with and without
cap thread, with various threads, splines, heights and closing dephts. They are suitable for
passing the tests of the various international approval institutes

SPECIAL CARTRIDGES

These cartridges are manufactured according to customer specifications. The
design is realised upon drawing or sample, allowing an almost unlimited number
of possible solutions. In addition to the different technical specifications and
sizes that can be modified and adapted to the customer's needs, special attention is also paid to heat treatment (annealing) and surface treatments (nickel
plating or chrome plating) that allow us to offer the widest range of solutions.

These are the modern, absolutely guaranteed, high quality cartridges in which the rubber sealing washer has been replaced by ceramic discs that open or close the water with only 90° or 180° turning and a silicone gasket. They are available in various sizes and can be customised on request.

They can be used with normal water flow (inlet from the lower gasket and outlet from the side windows) or, with a specific gasket to be requested, also with reverse flow (inlet from the side windows and outlet from the lower gasket). Versions with
vertical flow (water inlet from below and outlet from the rod through a longitudinal hole) are also available
