Volcano Thermostat
In terms of design concept, our panels are inspired by volcanic craters. The exterior design is ultra-thin, square on the outside and round on the inside, simple and elegant. The operation area is equipped with a four-petal touch area, and the gray icons are simple and elegant. The operation is divided into blocks to present a design that "arches" toward the center, highlighting important information on the interface. It adopts black and white color scheme to show a simple and technological appearance. In standby mode, the interface presents a holographic screen state without any icons displayed; once started or operated, the interface icons are clear and detailed. The professionally designed wide-width fonts are tilted at an angle that brings a strong visual impact.

Technical Parameter
Model: RT－V１ （heating）；RT－V１W（heating with wifi)；RT－V２(heating and cooling)
Voltage: 100-240VAC~50/60Hz
Temperature control range: internal5℃ ~ 35℃ / external 5℃ ~ 60℃
Temperature control accuracy: ±1C
Temperature sensor: NTC
Housing material: PC flame retardant
Load current: 3A(MAX)
Dimension: 86mmX86mmX12.8mm
Color: White/Black/White&Black

910010CC Thermostatic Mixing Valve
Thermostatic mixing valves (15MM TMV3&22MM TMV3) are specified to meet the specification D 08: thermostatic mixing valves (healthcare premises), comfort and economy as demanded by today’s users. All Smlege products are designed, manufactured and supported in accordance with accredited ISO 9001:2015 Quality Systems.

Feature

Resist against fluctuation of pressure and temperature

Water-break safety and burn prevention

Anti-scale and resistance against wear

Valve body material：DR brass

Technical Parameter

Accuracy：±2.0℃

Factory Temperature Setting：38℃

Maximum static pressure：10bar

Flow pressure (High pressure)：1bar to 5bar

Flow pressure (Low pressure)：0.2bar to 1bar

Hot supply temperature：55℃ to 65℃

Cold supply temperature：5℃ to 20℃

The wax thermostatic element produced by the SMLG with its own patented formula is widely recognized , praised and applied in the industry for its sensitivity and accuracy . It has also passed the European experimental institutions product certification ( ACS , WRAS ).


Application:


Military Plumbing

Sanitary Automobile

Shipping Air Conditioning Other Industries

Technical Parameter

Maximum Load 140N

Minimum Load 45N

Testing Load 85N

Spring Rate 5N/mm

Maximum Temperature 100°C

Material Copper

Stroke:L= 24±0.5mm at 25°C 55N

920062PL

Thermal actuator with manual opening and position indicator

The actuators are mainly used in floor heating systems to control closing and opening of the valves. It is specifically applied to electric drive part of the branch manifold valve, small valve and dynamic balance valve.



Feature：

Compact size, small dimensions

Fast installation and disassembly

Noiseless

Low power consumption

Full view stroke indication

Temperature control in intelligent HVAC systems on the market not aimed at energy saving will end nowhere- starting with the use of room thermostats and terminal thermal actuators.

As a part of temperature controller, thermal actuator is widely used in underfloor heating and ceiling radiant heating and cooling systems, air conditioning systems, radiator heating systems, and other systems that require temperature control or fluid on-off control, automatically switch the controlled loops by receiving signals from room thermostats or other electrical switches. By the way , it is worth mentioning that electric thermal actuators are still the most widely used in floor heating system. Usually used in combination with an underfloor heating manifold.
