Volcano Thermostat
In terms of design concept, our panels are inspired by volcanic craters. The exterior design is ultra-thin, square on the outside and round on the inside, simple and elegant. The operation area is equipped with a four-petal touch area, and the gray icons are simple and elegant. The operation is divided into blocks to present a design that "arches" toward the center, highlighting important information on the interface. It adopts black and white color scheme to show a simple and technological appearance. In standby mode, the interface presents a holographic screen state without any icons displayed; once started or operated, the interface icons are clear and detailed. The professionally designed wide-width fonts are tilted at an angle that brings a strong visual impact.

Technical Parameter
Model: RT－V１ （heating）；RT－V１W（heating with wifi)；RT－V２(heating and cooling)
Voltage: 100-240VAC~50/60Hz
Temperature control range: internal5℃ ~ 35℃ / external 5℃ ~ 60℃
Temperature control accuracy: ±1C
Temperature sensor: NTC
Housing material: PC flame retardant
Load current: 3A(MAX)
Dimension: 86mmX86mmX12.8mm
Color: White/Black/White&Black

Multi-channel Wired Base Station 8 zones

Wired base station is the central connection unit of a room-by -room temperature control for the surface temperature adjustment of heating systems. Base station is available in the versions with 8 zones in 230 V. With minimum expense, it can be wired to all system components as e. g. thermostats and actuators. The system components are supplied directly with the voltage supply of base station. All switching commands for the thermostats are forwarded directly to the connected system components.

Technical Parameter

Working voltage:230V±10%

Material:ABS

Control direction: normally closed

Control area:8 zones

Max control thermostat number:8pcs

Max control actuator number: 16pcs

Fuse:5-10A

Protection:IP20

Standard:E 60730-2

910010CC Thermostatic Mixing Valve
Thermostatic mixing valves (15MM TMV3&22MM TMV3) are specified to meet the specification D 08: thermostatic mixing valves (healthcare premises), comfort and economy as demanded by today’s users. All Smlege products are designed, manufactured and supported in accordance with accredited ISO 9001:2015 Quality Systems.

Feature

Resist against fluctuation of pressure and temperature

Water-break safety and burn prevention

Anti-scale and resistance against wear

Valve body material：DR brass

Technical Parameter

Accuracy：±2.0℃

Factory Temperature Setting：38℃

Maximum static pressure：10bar

Flow pressure (High pressure)：1bar to 5bar

Flow pressure (Low pressure)：0.2bar to 1bar

Hot supply temperature：55℃ to 65℃

Cold supply temperature：5℃ to 20℃

920062PL

Thermal actuator with manual opening and position indicator

The actuators are mainly used in floor heating systems to control closing and opening of the valves. It is specifically applied to electric drive part of the branch manifold valve, small valve and dynamic balance valve.



Feature：

Compact size, small dimensions

Fast installation and disassembly

Noiseless

Low power consumption

Full view stroke indication

Temperature control in intelligent HVAC systems on the market not aimed at energy saving will end nowhere- starting with the use of room thermostats and terminal thermal actuators.

As a part of temperature controller, thermal actuator is widely used in underfloor heating and ceiling radiant heating and cooling systems, air conditioning systems, radiator heating systems, and other systems that require temperature control or fluid on-off control, automatically switch the controlled loops by receiving signals from room thermostats or other electrical switches. By the way , it is worth mentioning that electric thermal actuators are still the most widely used in floor heating system. Usually used in combination with an underfloor heating manifold.
