Wisa XS WC Variotronic

A small adjustment, makes a world of difference

The electronically height-adjustable VarioTronic WC solution easily enables adjustment of the height of a wall-hung WC to cater for varied user requirements.

The concealed, wall-mounted, height-adjustable flushing cistern is specially developed for hospitals, care homes, inclusive washrooms and care organisations, to maintain independence and comfort for the user, and convenience for the caregiver.

Offering optimum accessibility, the VarioTronic design ensures comfort for all users, making it easy to move from wheelchair to toilet. A standard-sized wall hung WC offers the perfect fit for washrooms and bathrooms.

The height of the toilet can be easily adjusted by 20 cm (-2cm/+18 cm) using a handy remote control. The minimum height of the wall-hung WC (to the top of the rim) is 38 cm and the maximum height is 58 cm.

Both sides, as well as the shelf are finished in stainless steel panels, which can be quickly and easily accessed for maintenance and servicing. The front of the product can be finished in white HPL or upgraded to safety glass which is available in black or white. Optional folding arm supports are also available in black or white.

Key Features:
• Slim, concealed toilet wall-mounting system which makes manoeuvring next to it in a wheelchair easy
• Contemporary, attractive design
• Sides and walls finished in high-quality stainless steel
• Easy servicing and maintenance accessed via the side panels
• Static load capacity up to 400 kg
• People up to 180 kg can be raised
• Arm supports can be completely folded up next to the frame for optimum transfer
• Arm supports move with the system
• Simple attachment / dismantling of arm supports
• The concealed wall-mounted system is easy to assemble
• Available with any XS control panel, mechanical, pneumatic or electronic

With WISA XS and XT, we offer a new generation of concealed cisterns; developed and produced by and for professionals. During the development WISA was assisted by an extensive panel of installers. The practical experience of those people learned that next to installation ease and trustworthiness, also aesthetics and efficiency are important. This knowledge, combined with the yearlong experience that we have in flushing technique, was the base of the development of WISA XS and XT. With WISA XS and XT we offer a complete series of concealed cisterns, for both wet and dry processing.

• Pre-installed WC cistern with support frame
• Blue powder coated frame
• Adjustable feet (20 cm)
• Dual flush 3/6 L or 6 L flush interruption depending on control panel
• Flush volume adjustable between 6 and 7.5 L
• Insulated against condensation
• Quiet hydraulic float valve
• Pre-installed stop valve
• Water connection 1/2”
• Pre-assembled wall fixation kit
• Incl. WC connection kit, fixation materials, masonry aid, discharge elbow PE 90 mm with reducer to 110 or 100 mm
• Incl. insulation kit for pan to wall
• CE EN 14055 - CL1-6- NL I - VR I

747EL Side Entry Fill Valve with 3/8" Heavy Duty Brass Shank

3/8″ Heavy Duty Brass Shank

Installation method

• Installation in prefabricated walls, pre-wall installation in dry walls, universal installation into solid walls

Properties

• Supporting, blue powder coated WC element, square profile 40x30 mm with pre-assembled 199 UP concealed cistern
• Frontal flushing, for dual flushing (3/6 L)
• Flush volume adjustable (large flush 4.5-9 L, small flush 2.5-4.5 L)
• Pre-assembled wall brackets and adjustable feet (0-200 mm)
• Water connection - top center
• Fully insulated against condensation

Special features

• Quiet Hydraulic Fill valve (Noise class 1 ISO 3822)
• Depth adjustable drain elbow (+/-20 mm)

Product contains

• Concealed cistern equipped with pre-installed stop valve – top center
• Water connection 1/2”
• PE drain elbow Ø 90 mm with seal
• PE adapter Ø 90 / 110 mm with seal
• Complete installation and fixing material
• Flushing plate needs to be ordered separately
