Art. 523 - Adjustable noiseless float valve in pressed brass

The self-cleaning filter is suitable for all plants, both civil and industrial ones, where the constant impurities in water could damage or block the present appliances. The water, we usually use, comes from waterworks or wells, contains a great number of particles which, according to their sizes, interact negatively with the installed accessories and compromise, therefore, their correct functioning. The joints for the connection to the hydraulic plant are internal threaded in compliance with the ISO 228/1 standard. On the body of the self-cleaning filter there are two 1⁄4"G threads for the connection of two pressure gauges.

Available sizes: 1/2”G - 3/4”G - 1”G - 1”1/4 G - 1”1/2 G - 2”G

Technical informations

Maximum recommended working pressure 16 bar.

Filtering mesh:
400 micron (standard 1/2"-2").

Maximum using temperature 80°C.

Materials:
CB770S UNI EN 1982 -
CW617N UNI EN 12165 -
CW614N UNI EN 12164 -
AISI 304 -
EPDM -
POLIMID A SG -
PVC -
Nylon -
P.T.F.E.

This model is usually used in medium dimension tanks. Main feature is the closing through piston, directly controlled from the rod on which is assembled the ball, connected by a 5⁄16 W thread. Item completely compatible with the BS1212 standard.

Available sizes: 1/2”G

Technical informations

Maximum recommended working pressure:
527/1 - 6 bar 527/2 - 12 bar.
Maximum recommended working:
temperature 80°C.
Materials:
CW617N UNI EN 12165 -
CW614N UNI EN 12164 -
CW508L UNI EN 12166 - PVC -
NBR - Hostaform C13031 -
Fasit 202.

GLOBUS quick-fit BAll-operated noisless float valve in hot-pressed brass, complete with inlet pipe and flat rod.
Patented ball operation, ensuring unique noiselessness and total invulnerability to vibrations.
The valve body and the inner brass ball has undergone T.E.A.+ surface treatment.
The chrome-plated ball and PTFE seats ensure maximum seal, while a filter at the valve inlet ensures that no damage is caused by impurities.
The new quick-fit connection system simplifies installation and maintenance.
The valve comes with plastic inlet hose, reducing the noise caused by the fall of water into the tank.

Available sizes: 1/2”G - 3/4”G - 1”G - 1”1/4 G

Technical informations

Maximum recommended working pressure 12 bar.

Maximum recommended working temperature 80°C.

Materials:
CW617N UNI EN 12165 -
CW614N UNI EN 12164 -
EPDM -
PTFE -
AISI 304 -
AISI 430 –
PVC

F.F. pressure reducing valve is particularly indicated in both civil aswell as industrial installations where medium-high flows are required, with the guarantee of the stainless steel tightness seat. The main feature is the piston operation with compensation chamber. The joints for the connection to the hydraulic plant are internal threaded in compliance with the ISO 228/1 standard. On the body there are two 1⁄4"G threads for the connection of a pressure gauge.

Available sizes: 1/2”G - 3/4”G - 1”G - 1”1/4 G - 1”1/2 G - 2”G - 2"1/2G - 3"G - 4"G

Technical informations
Maximum recommended working pressure 25 bar.

Regulation: F.F. pressure reducing valve is tested and calibrated to an exit pressure of 3 bar.

Outflow pressure adjustment field:
1/2"G - 3/4"G - 1"G 0,5-6 bar.
1"1/4G - 1"1/2G - 2"G 1-6 bar.
2"1/2G - 3"G - 4"G 1-7 bar.

Maximum using temperature 120°C.

Materials:
CW617N UNI EN 12165 -
CW614N UNI EN 12164 -
CB770S UNI EN1982 (2"1/2 - 3") -
C 72 DIN 17223-84 -
AISI 304 -
EPDM -
POLIMID A SG.

The self-cleaning filter is suitable for all plants, both civil and industrial ones, where the constant impurities in water could damage or block the present appliances. The water, we usually use, comes from waterworks or wells, contains a great number of particles which, according to their sizes, interact negatively with the installed accessories and compromise, therefore, their correct functioning. The joints for the connection to the hydraulic plant are internal threaded in compliance with the ISO 228/1 standard. On the body of the self-cleaning filter there are two 1⁄4"G threads for the connection of two pressure gauges.

Available sizes: 1/2”G - 3/4”G - 1”G - 1”1/4 G - 1”1/2 G - 2”G

Technical informations

Maximum recommended working pressure 16 bar.

Filtering mesh:
400 micron (standard 1/2"-2").

Maximum using temperature 80°C.

Materials:
CB770S UNI EN 1982 -
CW617N UNI EN 12165 -
CW614N UNI EN 12164 -
AISI 304 -
EPDM -
POLIMID A SG -
PVC -
Nylon -
P.T.F.E.

This model is usually used in medium dimension tanks. Main feature is the closing through piston, directly controlled from the rod on which is assembled the ball, connected by a 5⁄16 W thread. Item completely compatible with the BS1212 standard.

Available sizes: 1/2”G

Technical informations

Maximum recommended working pressure:
527/1 - 6 bar 527/2 - 12 bar.
Maximum recommended working:
temperature 80°C.
Materials:
CW617N UNI EN 12165 -
CW614N UNI EN 12164 -
CW508L UNI EN 12166 - PVC -
NBR - Hostaform C13031 -
Fasit 202.

GLOBUS quick-fit BAll-operated noisless float valve in hot-pressed brass, complete with inlet pipe and flat rod.
Patented ball operation, ensuring unique noiselessness and total invulnerability to vibrations.
The valve body and the inner brass ball has undergone T.E.A.+ surface treatment.
The chrome-plated ball and PTFE seats ensure maximum seal, while a filter at the valve inlet ensures that no damage is caused by impurities.
The new quick-fit connection system simplifies installation and maintenance.
The valve comes with plastic inlet hose, reducing the noise caused by the fall of water into the tank.

Available sizes: 1/2”G - 3/4”G - 1”G - 1”1/4 G

Technical informations

Maximum recommended working pressure 12 bar.

Maximum recommended working temperature 80°C.

Materials:
CW617N UNI EN 12165 -
CW614N UNI EN 12164 -
EPDM -
PTFE -
AISI 304 -
AISI 430 –
PVC
