Bracket O2 is universal for all types of bathroom radiators. It is suitable for fixing of flat and round radiators. Its flexible head is fixed between the pipes of the radiator.

(dimension 20- 22 Ø).

Packed: 4 plastic brackets, 4 plugs and 4 screws (packed in a small cardboard box).

Packing with air vent and blind plug ½’’ is possible

Bracket CAK is designed for radiators without welded hangers on the rear side (for Ventil Kompakt radiators). The bracket holds the lower and top edge (top cover) of the
radiator. The upper holder is made of PA plastic with 30% of glass fibres which gives it excellent firmness. The plastic part of the holder is covered with metal cap which
fastens on the top cover of the radiator. Bracket CAK excels in quick fixing as the upper plastic holder automatically springs into position and locks the radiator. The height
of the bracket CAK is the same for all brands of radiators.
CAK-L is suitable for radiators typ 11!

Instructions:
Dimension of the upper holder depends on the brand of the radiator (top cover). CAK1 - upper holder 7 mm CAK2 - upper holder 10 mm * The dimension of the upper
holder needs to be specified in the order.

Code Height Packgaing

1560 CAK-300 25
1561 CAK-400 25
1562 CAK-500 25
1563 CAK-600 25
1564 CAK-700 25
1565 CAK-800* 20
1566 CAK-900* 20

Packed /set:
2 brackets, 2 plugs Ø10 and 2 screws M8×70. * additional set: 2 plugs Ø10 and 2 screws M8×70
